Buckner Storm

Buckner-Storm Impact Sprinklers: 1/2", 3/4" 1" and 1-1/4" inch inlet

Buckner-Storm 65P10 Plastic Impact Sprinkler

Impact Sprinkler Model 65P - 1/2" Full/Part Circle, Buckner-Storm

20° to 340° arc or full circle operation. Anti-backsplash drive arm. Adjustable deflector plate. Adjustable diffuser pin. Stainless steel drive spring. Chemical resistant bearing seals. ½" NPT male inlet. Pressure: 25-60 psi.

Item # Description Price Weight Cart
65P10 Full/Part circle, heavy duty plastic, 1/2" Inlet. (optional nozzles available) $5.99 0.5lb Buy

Call for freight reduction on larger quantities.

Buckner-Storm 90SD Brass Impact Sprinkler

Impact Sprinkler Model 90SD - 1/2" Brass Full/Part Circle, Buckner-Storm

Solid brass construction. Manganese bronze die-cast drive arm. Patented spray distribution grooves. Anti-backsplash arm. Stainless steel drive spring and trip assembly. "Sure Seal®" sand load bearing assembly. 20° to 340° arc or full circle. Chemical resistant bearing seals. Adjustable deflector plate. Solid brass nozzle. Stream straightener vane. ½" NPT male inlet. Pressure 25-55 psi.

Item # Description Price Weight Cart
90SD Full/Part circle, heavy duty brass, 1/2" Inlet. $27.59 1.0lb Buy

Call for freight reduction on larger quantities.

Buckner-Storm 17023R Brass Impact Sprinkler

Impact Sprinkler Model 17023R - 1/2" Brass Full Circle, Buckner-Storm

Solid brass construction. Stainless steel drive spring. "Sure Seal®" sand load bearing assembly. Bearing assembly hood for longer wear life. Chemical resistant bearing seals. 23° angle of trajectory. Stainless steel spindle. Solid brass nozzle. ½" NPT male inlet. 3/8"-24 UNF nozzle thread. Pressure 25-60 psi.

Item # Description Price Weight Cart
17023R Full circle, heavy duty brass, 23° trajectory, 1/2" Inlet. $13.59 1.0lb Buy

Call for freight reduction on larger quantities.

Buckner-Storm 2000SX Brass Impact Sprinkler

Impact Sprinkler Model 2000SX - 3/4" Brass Full Circle, Buckner-Storm

Solid brass construction. Stainless steel drive spring. "Sure Seal®" sand load bearing assembly. Bearing assembly hood for longer wear life. Chemical resistant bearing seals. Stream straightener standard. Stainless steel spindle. Solid brass nozzle. Use plug for single nozzle. 3/4" NPT male inlet. 3/8"-24 UNF range side nozzle thread. 1/4"-18 NPT drive side nozzle thread Pressure 35-80 psi.

Item # Description Price Weight Cart
2000SX Full circle, heavy duty brass, dual opposed nozzles, 3/4" Inlet. $20.99 1.0lb Buy

Call for freight reduction on larger quantities.

Buckner-Storm 261SDX Brass Impact Sprinkler

Impact Sprinkler Model 261SDX - 3/4" Brass Full/Part Circle, Buckner-Storm

Solid brass construction. Anti-backsplash arm. 20° to 340° arc or full circle. Stainless steel drive spring. "Sure SealŪ" sand load bearing assembly. Chemical resistant bearing seals. Stainless steel trip assembly and collars. Adjustable diffuser pin. Adjustable deflector plate. Solid brass nozzle. Use plug for single nozzle. 3/4" NPT male inlet. 3/8"-24 UNF lower nozzle thread. 1/4"-18 NPT top drive nozzle thread. Pressure 30-60 psi.

Item # Description Price Weight Cart
261SDX Full/Part circle, heavy duty brass, dual nozzles, 3/4" Inlet. $38.59 1.5lb Buy

Call for freight reduction on larger quantities.

Buckner-Storm 360SA Brass Impact Sprinkler

Impact Sprinkler Model 360SA - 1" Brass Full/Part Circle, Buckner-Storm

Solid brass construction. 20° to 340° arc or full circle. Stainless steel drive spring. "Sure SealŪ" sand load bearing assembly. Chemical resistant bearing seals. Cast brass trip assembly. Stainless steel trip collars. Adjustable diffuser pin. Solid brass nozzle. Use plug for single nozzle.1" NPT male inlet. 3/8"-24 UNF lower nozzle thread. 5/8"-18 UNF top drive nozzle thread. Optional British Pipe Thread available. Pressure 35-100 psi.

Item # Description Price Weight Cart
360SA Full/Part circle, heavy duty brass, dual nozzles, 1" Inlet. $70.99 2.5lb Buy

Call for freight reduction on larger quantities.

Buckner-Storm 350SAX Brass Impact Sprinkler

Impact Sprinkler Model 350SAX - 1" Brass Full Circle, Buckner-Storm

Solid brass construction. Stainless steel drive spring. "Sure SealŪ" sand load bearing assembly. Chemical resistant bearing seals. Bearing assembly hood for longer wear life. Adjustable diffuser pin. Solid brass nozzles on same side. Use plug for single nozzle.1" NPT male inlet. 3/8"-24 UNF lower nozzle thread. 5/8"-18 UNF top drive nozzle thread. Optional British Pipe Thread available. Pressure 40-80 psi.

Item # Description Price Weight Cart
350SAX Full circle, heavy duty brass, dual nozzles, 1" Inlet. $46.59 2.5lb Buy

Call for freight reduction on larger quantities.

Buckner-Storm 300SAX Brass Impact Sprinkler

Impact Sprinkler Model 300SAX - 1" Brass Full Circle, Buckner-Storm

Solid brass construction. Stainless steel drive spring. "Sure SealŪ" sand load bearing assembly. Chemical resistant bearing seals. Bearing assembly hood for longer wear life. Adjustable diffuser pin. Solid brass opposing nozzles. Use plug for single nozzle.1" NPT male inlet. 5/8"-18 UNF range nozzle thread. 1/4"-18 NPT drive nozzle thread. Optional British Pipe Thread available. Pressure 40-80 psi.

Item # Description Price Weight Cart
300SAX Full circle, heavy duty brass, dual nozzles, 1" Inlet. $52.99 2.5lb Buy

Call for freight reduction on larger quantities.

Buckner-Storm 300SAX Brass Impact Sprinkler

Impact Sprinkler Model 400S - 1-1/4" Brass Full Circle, Buckner-Storm

Solid brass construction. Stainless steel drive spring. "Sure Seal®" sand load bearing assembly. Chemical resistant bearing seals. Adjustable diffuser pin. Solid brass opposing nozzles. Use plug for single nozzle. Range tube for improved throw. 1-1/4" NPT male inlet.3/4"-16 UNF range nozzle thread. 3/4"-16 UNF drive nozzle thread. Optional British Pipe Thread available. Pressure 65-100 psi.

Item # Description Price Weight Cart
400S Full circle, heavy duty brass, dual nozzles, range tube, 1-1/4" Inlet. $115.59 3.0lb Buy

Call for freight reduction on larger quantities.

Buckner-Storm AI120 Brass Impact Sprinkler

Impact Sprinkler Model AI120 - 1-1/4" Brass Full Circle, Buckner-Storm

Solid brass construction. Stainless steel drive spring. 23° trajectory. Inner break-up/spreader nozzle provides uniform water distribution. Stream straighteners ensure maximum radius, superior high wind performance. Solid brass nozzle. 1-1/4" NPT male inlet 1"-20 UNF top nozzle thread. 1/8"-27 NPT lower nozzle thread. Optional British Pipe Thread available. Pressure 55-95 psi.

Item # Description Price Weight Cart
AI120 Full circle, heavy duty brass, dual nozzles, 1-1/4" Inlet. $152.59 3.0lb Buy

Call for freight reduction on larger quantities.

Buckner-Storm AI123 Brass Impact Sprinkler

Impact Sprinkler Model AI123 - 1-1/4" Brass Full/Part Circle, Buckner-Storm

Solid brass construction. Stainless steel drive spring. 23° trajectory. Inner break-up/spreader nozzle provides uniform water distribution. Stream straighteners ensure maximum radius, superior high wind performance. Solid brass nozzle. 1-1/4" NPT male inlet 1"-20 UNF top nozzle thread. 1/8"-27 NPT lower nozzle thread. Optional British Pipe Thread available. Pressure 55-95 psi.

Item # Description Price Weight Cart
AI123 Full/Part circle, heavy duty brass, dual nozzles, 1-1/4" Inlet. $163.99 3.0lb Buy

Call for freight reduction on larger quantities.


Orbit Irrigation

Orbit 55032 Brass Impact Sprinkler

Impact Sprinkler Model 55032 - 1/2" Brass Full/Part Circle, Orbit

The Brass Impact Head works with or replaces 1/2 In. impact or impulse heads. It covers areas of 25 Ft. to 40 Ft. radius and can be adjusted from a partial to full circle. 1/2" NPT male inlet.

Item # Description Price Weight Cart
55032 Full/Part circle, brass, 1/2" Inlet. $12.99 1.0lb Buy

Call for freight reduction on larger quantities.

Orbit 55015 Brass Impact Sprinkler

Impact Sprinkler Model 55015 - 1/2" Zinc Full/Part Circle, Orbit

Impact Sprinkler Head is constructed of zinc designed to water up to an 80 Ft. diameter. The easily adjustable spray nozzle can be modified from a partial to full circle. The 1/2 In. Impact Sprinkler Head also features a deflector shield and anti-backsplash arm to aid in spray pattern and area coverage. 1/2" NPT male inlet.

Item # Description Price Weight Cart
55015 Full/Part circle, zinc, 1/2" Inlet. $6.99 1.0lb Buy

Call for freight reduction on larger quantities.

Orbit 55016 Brass Impact Sprinkler

Impact Sprinkler Model 55016 - 3/4" Brass Full/Part Circle, Orbit

Double brass 3/16 in. and 3/32" nozzles, area coverage 25 ft. - 48 ft. radius - Full of part circle, Stainless steel arm spring, trip spring, trip collars, and trip pin, Anti-backsplash tube. 3/4" NPT male inlet.

Item # Description Price Weight Cart
55016 Full/Part circle, brass, 3/4" Inlet. $35.99 1.5lb Buy

Call for freight reduction on larger quantities.

Orbit H2O-6 Gear Drive Sprinkler

Gear Drive Sprinkler Model H2O-6

The H2O-6 Gear Drive Sprinkler Head has six easy to adjust spray patterns. Simply rotate the head and click the pattern into position; no tools required! The three position diffuser allows you complete spray control spray 15 to 30 ft. Slide tabs to set right and left rotating stops; changing the spray pattern anywhere from 25 to 360 degrees. Unique Design - Out performs the competition! 360-Degree Coverage - Easy to-adjust tabs make it simple; High-Impact Construction - Durable for years of use.

Item # Description Price Weight Cart
H20-6 Gear Drive Sprinkler $21.99 1.5lb Buy

Call for freight reduction on larger quantities.

Orbit H2O-6 Gear Drive Sprinkler

1/2" Brass Impact Sprinkler on Metal Ring

This sprinkler is ideal for large area watering. Easily adjusts from full to part circle. Area coverage 85' Diameter. Adjustable from full to partial circle. Distance adjustment and anti-backsplash arm. For outdoor use with cold water only.

Item # Description Price Weight Cart
55033 1/2" Brass Impact Sprinkler on Metal Ring $20.99 4.0lbs Buy

Out of stock until Spring of 2013
Call for freight reduction on larger quantities.
